TP Final : Plateforme Production
Objectifs
- Déployer une application complète production-ready
- Implémenter la haute disponibilité
- Configurer la sécurité end-to-end
- Mettre en place le monitoring et l'alerting
Durée : 2 heures
Scénario
Vous êtes l'architecte Kubernetes chez CloudShop, une startup e-commerce. Vous devez déployer leur plateforme sur Kubernetes avec les exigences suivantes :
- Haute disponibilité (multi-replicas)
- Sécurité (RBAC, Network Policies, Pod Security)
- Observabilité (Prometheus, Grafana)
- GitOps ready
Architecture
ARCHITECTURE CLOUDSHOP
══════════════════════
┌─────────────────┐
│ Ingress │
│ Controller │
└────────┬────────┘
│
┌────────────────┼────────────────┐
│ │ │
▼ ▼ ▼
┌──────────┐ ┌──────────┐ ┌──────────┐
│ Frontend │ │ API │ │ Admin │
│ (React) │ │ (Go) │ │ (Vue) │
│ 3 pods │ │ 5 pods │ │ 2 pods │
└────┬─────┘ └────┬─────┘ └──────────┘
│ │
│ ┌──────┴──────┐
│ │ │
│ ▼ ▼
│ ┌─────────┐ ┌─────────┐
│ │PostgreSQL│ │ Redis │
│ │(StatefulSet)│ │(Cluster)│
│ │ 3 pods │ │ 3 pods │
│ └─────────┘ └─────────┘
│
▼
┌──────────┐
│ CDN/S3 │
│ (Static) │
└──────────┘
Partie 1 : Namespace et RBAC (20 min)
1.1 Créer les Namespaces
# namespaces.yaml
apiVersion: v1
kind: Namespace
metadata:
name: cloudshop-prod
labels:
name: cloudshop-prod
environment: production
pod-security.kubernetes.io/enforce: baseline
pod-security.kubernetes.io/warn: restricted
---
apiVersion: v1
kind: Namespace
metadata:
name: cloudshop-staging
labels:
name: cloudshop-staging
environment: staging
1.2 RBAC
# rbac.yaml
apiVersion: v1
kind: ServiceAccount
metadata:
name: cloudshop-api
namespace: cloudshop-prod
---
apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
name: cloudshop-api-role
namespace: cloudshop-prod
rules:
- apiGroups: [""]
resources: ["configmaps", "secrets"]
verbs: ["get", "list"]
- apiGroups: [""]
resources: ["pods"]
verbs: ["get", "list", "watch"]
---
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
name: cloudshop-api-binding
namespace: cloudshop-prod
subjects:
- kind: ServiceAccount
name: cloudshop-api
namespace: cloudshop-prod
roleRef:
kind: Role
name: cloudshop-api-role
apiGroup: rbac.authorization.k8s.io
Partie 2 : Base de Données (25 min)
2.1 PostgreSQL StatefulSet
# postgres.yaml
apiVersion: v1
kind: Secret
metadata:
name: postgres-secret
namespace: cloudshop-prod
type: Opaque
stringData:
POSTGRES_USER: cloudshop
POSTGRES_PASSWORD: "S3cur3P@ssw0rd!"
POSTGRES_DB: cloudshop
---
apiVersion: v1
kind: Service
metadata:
name: postgres
namespace: cloudshop-prod
spec:
clusterIP: None
selector:
app: postgres
ports:
- port: 5432
---
apiVersion: apps/v1
kind: StatefulSet
metadata:
name: postgres
namespace: cloudshop-prod
spec:
serviceName: postgres
replicas: 1
selector:
matchLabels:
app: postgres
template:
metadata:
labels:
app: postgres
spec:
containers:
- name: postgres
image: postgres:15-alpine
ports:
- containerPort: 5432
envFrom:
- secretRef:
name: postgres-secret
volumeMounts:
- name: data
mountPath: /var/lib/postgresql/data
resources:
requests:
cpu: 250m
memory: 512Mi
limits:
cpu: 1
memory: 1Gi
livenessProbe:
exec:
command: ["pg_isready", "-U", "cloudshop"]
initialDelaySeconds: 30
periodSeconds: 10
readinessProbe:
exec:
command: ["pg_isready", "-U", "cloudshop"]
initialDelaySeconds: 5
periodSeconds: 5
volumeClaimTemplates:
- metadata:
name: data
spec:
accessModes: ["ReadWriteOnce"]
resources:
requests:
storage: 10Gi
2.2 Redis
# redis.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
name: redis
namespace: cloudshop-prod
spec:
replicas: 1
selector:
matchLabels:
app: redis
template:
metadata:
labels:
app: redis
spec:
containers:
- name: redis
image: redis:7-alpine
ports:
- containerPort: 6379
resources:
requests:
cpu: 100m
memory: 128Mi
limits:
cpu: 500m
memory: 256Mi
readinessProbe:
tcpSocket:
port: 6379
initialDelaySeconds: 5
periodSeconds: 5
---
apiVersion: v1
kind: Service
metadata:
name: redis
namespace: cloudshop-prod
spec:
selector:
app: redis
ports:
- port: 6379
Partie 3 : Application (30 min)
3.1 API Backend
# api.yaml
apiVersion: v1
kind: ConfigMap
metadata:
name: api-config
namespace: cloudshop-prod
data:
DATABASE_HOST: postgres
DATABASE_PORT: "5432"
REDIS_HOST: redis
REDIS_PORT: "6379"
LOG_LEVEL: info
---
apiVersion: apps/v1
kind: Deployment
metadata:
name: api
namespace: cloudshop-prod
spec:
replicas: 3
selector:
matchLabels:
app: api
template:
metadata:
labels:
app: api
annotations:
prometheus.io/scrape: "true"
prometheus.io/port: "8080"
prometheus.io/path: "/metrics"
spec:
serviceAccountName: cloudshop-api
securityContext:
runAsNonRoot: true
runAsUser: 1000
fsGroup: 1000
containers:
- name: api
image: cloudshop/api:v1.0.0
ports:
- containerPort: 8080
name: http
envFrom:
- configMapRef:
name: api-config
env:
- name: DATABASE_USER
valueFrom:
secretKeyRef:
name: postgres-secret
key: POSTGRES_USER
- name: DATABASE_PASSWORD
valueFrom:
secretKeyRef:
name: postgres-secret
key: POSTGRES_PASSWORD
resources:
requests:
cpu: 100m
memory: 128Mi
limits:
cpu: 500m
memory: 512Mi
securityContext:
allowPrivilegeEscalation: false
readOnlyRootFilesystem: true
capabilities:
drop:
- ALL
livenessProbe:
httpGet:
path: /health/live
port: 8080
initialDelaySeconds: 10
periodSeconds: 10
readinessProbe:
httpGet:
path: /health/ready
port: 8080
initialDelaySeconds: 5
periodSeconds: 5
---
apiVersion: v1
kind: Service
metadata:
name: api
namespace: cloudshop-prod
spec:
selector:
app: api
ports:
- port: 80
targetPort: 8080
3.2 Frontend
# frontend.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
name: frontend
namespace: cloudshop-prod
spec:
replicas: 2
selector:
matchLabels:
app: frontend
template:
metadata:
labels:
app: frontend
spec:
containers:
- name: frontend
image: cloudshop/frontend:v1.0.0
ports:
- containerPort: 80
resources:
requests:
cpu: 50m
memory: 64Mi
limits:
cpu: 200m
memory: 128Mi
livenessProbe:
httpGet:
path: /
port: 80
initialDelaySeconds: 5
periodSeconds: 10
---
apiVersion: v1
kind: Service
metadata:
name: frontend
namespace: cloudshop-prod
spec:
selector:
app: frontend
ports:
- port: 80
Partie 4 : Ingress et Network Policies (15 min)
4.1 Ingress
# ingress.yaml
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
name: cloudshop-ingress
namespace: cloudshop-prod
annotations:
nginx.ingress.kubernetes.io/ssl-redirect: "true"
nginx.ingress.kubernetes.io/proxy-body-size: "10m"
cert-manager.io/cluster-issuer: letsencrypt-prod
spec:
ingressClassName: nginx
tls:
- hosts:
- cloudshop.example.com
- api.cloudshop.example.com
secretName: cloudshop-tls
rules:
- host: cloudshop.example.com
http:
paths:
- path: /
pathType: Prefix
backend:
service:
name: frontend
port:
number: 80
- host: api.cloudshop.example.com
http:
paths:
- path: /
pathType: Prefix
backend:
service:
name: api
port:
number: 80
4.2 Network Policies
# network-policies.yaml
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
name: default-deny
namespace: cloudshop-prod
spec:
podSelector: {}
policyTypes:
- Ingress
- Egress
---
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
name: api-policy
namespace: cloudshop-prod
spec:
podSelector:
matchLabels:
app: api
policyTypes:
- Ingress
- Egress
ingress:
- from:
- podSelector:
matchLabels:
app: frontend
- namespaceSelector:
matchLabels:
name: ingress-nginx
ports:
- protocol: TCP
port: 8080
egress:
- to:
- podSelector:
matchLabels:
app: postgres
ports:
- protocol: TCP
port: 5432
- to:
- podSelector:
matchLabels:
app: redis
ports:
- protocol: TCP
port: 6379
- to:
- namespaceSelector: {}
podSelector:
matchLabels:
k8s-app: kube-dns
ports:
- protocol: UDP
port: 53
---
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
name: postgres-policy
namespace: cloudshop-prod
spec:
podSelector:
matchLabels:
app: postgres
policyTypes:
- Ingress
ingress:
- from:
- podSelector:
matchLabels:
app: api
ports:
- protocol: TCP
port: 5432
Partie 5 : Autoscaling et Monitoring (20 min)
5.1 HPA
# hpa.yaml
apiVersion: autoscaling/v2
kind: HorizontalPodAutoscaler
metadata:
name: api-hpa
namespace: cloudshop-prod
spec:
scaleTargetRef:
apiVersion: apps/v1
kind: Deployment
name: api
minReplicas: 3
maxReplicas: 10
metrics:
- type: Resource
resource:
name: cpu
target:
type: Utilization
averageUtilization: 70
- type: Resource
resource:
name: memory
target:
type: Utilization
averageUtilization: 80
5.2 ServiceMonitor
# servicemonitor.yaml
apiVersion: monitoring.coreos.com/v1
kind: ServiceMonitor
metadata:
name: cloudshop-api
namespace: monitoring
labels:
release: prometheus
spec:
selector:
matchLabels:
app: api
namespaceSelector:
matchNames:
- cloudshop-prod
endpoints:
- port: http
path: /metrics
interval: 30s
5.3 PrometheusRule
# alerts.yaml
apiVersion: monitoring.coreos.com/v1
kind: PrometheusRule
metadata:
name: cloudshop-alerts
namespace: monitoring
labels:
release: prometheus
spec:
groups:
- name: cloudshop.rules
rules:
- alert: CloudshopAPIDown
expr: up{job="cloudshop-api"} == 0
for: 1m
labels:
severity: critical
annotations:
summary: "CloudShop API is down"
- alert: CloudshopHighLatency
expr: |
histogram_quantile(0.95,
sum(rate(http_request_duration_seconds_bucket{job="cloudshop-api"}[5m])) by (le)
) > 0.5
for: 5m
labels:
severity: warning
annotations:
summary: "CloudShop API P95 latency > 500ms"
Validation
Checklist
- [ ] Namespaces créés avec Pod Security
- [ ] RBAC configuré
- [ ] PostgreSQL StatefulSet fonctionnel
- [ ] Redis déployé
- [ ] API avec probes et security context
- [ ] Frontend déployé
- [ ] Ingress avec TLS
- [ ] Network Policies appliquées
- [ ] HPA configuré
- [ ] ServiceMonitor actif
Commandes de Vérification
# Vérifier les ressources
kubectl get all -n cloudshop-prod
# Tester la connectivité
kubectl run test --rm -it --image=busybox -n cloudshop-prod -- wget -qO- http://api/health/ready
# Vérifier les Network Policies
kubectl get networkpolicies -n cloudshop-prod
# Vérifier le HPA
kubectl get hpa -n cloudshop-prod
# Vérifier le monitoring
kubectl get servicemonitors -n monitoring
Évaluation
| Critère | Points |
|---|---|
| Namespaces et RBAC | 15 |
| Base de données (PostgreSQL + Redis) | 20 |
| Application (API + Frontend) | 25 |
| Ingress et Network Policies | 20 |
| Autoscaling et Monitoring | 15 |
| Bonnes pratiques sécurité | 5 |
Total : 100 points Seuil de réussite : 70 points
